See below for specifications, cleaning instructions, and colour examples.
Euromesh 4500 Green vs Euromesh Classic Grey
Euromesh Classic Grey: Best resistance to UV but more expensive.
The original stockcrate fabric which we import from Japan and have been using for the last 25 years. A relatively expensive fabric, which is not helped by the fact that it is 1830mm wide and creates wasteful offcuts when making stockcrate covers.
Euromesh 4500 Green: Strongest and cheapest.
Stronger stockcrate fabric (tensile strength). We import it from Germany and have been using for 6 years. A cheaper fabric, and 3200mm wide which cuts efficiently with very little offcuts when making stockcrate covers.
Subject to change in view of technical upgrades. Values indicated are average nominal values for normal production (+/- 5%).
| Standard | Result | |
|---|---|---|
| Total Weight | EN ISO 2286-2 | 580gsm (4500 Green) or 530gsm (Classic Grey) |
| Openness Factor | PA 12.03 (intern) | 42% (4500 Green) or 52.6% (Classic Grey) |
| Tensile Strength (Warp/Weft) N/5cm | DIN 53354, DIN EN ISO 1421/V1 | 4000/4000 (4500 Green) or 3756/4083 (Classic Grey) |
| Tear Strength (Warp/Weft) | DIN 53363 | 1000/1000N (4500 Green) |
| Temperature Resistance | DIN EN 1876-1, PA 07.04 (intern) | -20ºC/+70ºC (4500 Green) |
| Translucence @ 550nm | 42% (4500 Green) or 52.6% (Classic Grey) | |
| Light Fastness | DIN EN ISO 105 B02 | >6 (4500 Green) |
| Seam Strength (2cm Seam) | DIN 53354 | 1500 N/5cm (4500 Green) |
| Air Permeability | DIN EN ISO 9237 | 7040 l/m2*sec (4500 Green) |
| Width | 3200mm (4500 Green) or 1870mm (Classic Grey) |
Please note: actual colour may vary. Contact us or visit our showroom to see colour samples. Always include the colour number when telling us your colour choice (e.g. Green ).
